The voltage regulators contain no electrolytic capacitors and are relatively unaffected by temperature, humidity, vibration and shock.ġ-2. The regulators consist of silicon controlled rectifiers (SCR's) transistors, transformers, silicon diodes, resistors and capacitors.
#REGULADOR VOLTAJE O SUPRESOR DE PICOS GENERATOR#
This includes brushless rotary exciters, brush type rotary exciters or direct excitation into the generator field of machines within the regulator's power rating. The SR4A and SR8A Voltage Regulators precisely control the output voltage of an ac electric generating system by controlling the amount of current supplied to the exciter (or generator) field. 5-5 Troubleshooting.5-5 Troubleshooting Chart. 5-3 Wiring Diagram.5-4 Warranty and Repair Service. SECTION 4.0 4.1 4.2 4.3 4.4 4.5 4.6 4.7 4.8 SECTION 5.0ĬONTENTS - ContinuedSECTION 5 MAINTENANCE, REPLACEMENT PARTS, AND TROUBLESHOOTING - Continued 5-2 Component Location and Identification. 4-4 MAINTENANCE, REPLACEMENT PARTS AND TROUBLESHOOTING. 3-7 Reactive Differential (Cross-Current) Compensation CT Interconnection. 3-7 Reactive Droop Compensation (Cross-Current).
3-5 Brushless Type Rotary Exciter (or Static Exciter) Interconnection. 3-2 Brush Type Rotary Exciter Interconnection. 3-2 Paralleling Potentiometer P/N (03469). 3-2 Voltage Adjust Potentiometer P/N (03456). 1-3 Model Number Description and Selection. Should further information be required, contact Basler Electric Company, Highland, Illinois.ĬONTENTSSECTION 1.0 1.1 1.2 GENERAL INFORMATION. The availability and design of all features and options are subject to modification without notice.
#REGULADOR VOLTAJE O SUPRESOR DE PICOS MANUAL#
It is not the intention of this manual to cover all details and variations in equipment, nor does this manual provide data for every possible contingency regarding installation or operation. IT IS LOANED FOR CONFIDENTIAL USE, SUBJECT TO RETURN ON REQUEST, AND WITH THE MUTUAL UNDERSTANDING THAT IT WILL NOT BE USED IN ANY MANNER DETRIMENTAL TO THE INTEREST OF BASLER ELECTRIC COMPANY. WARNING All SR4A and SR8A Voltage Regulators are shipped factory preset for 120 Vac sensing.įirst Printing: August 1971 Printed in USA 1997, Basler Electric Co., Highland, IL 62249 September 1997ĬONFIDENTIAL INFORMATIONOF BASLER ELECTRIC COMPANY, HIGHLAND, IL. WARNINGTO AVOID PERSONAL INJURY OR EQUIPMENT DAMAGE, ONLY QUALIFIED PERSONNEL SHOULD PERFORM THE PROCEDURES PRESENTED IN THIS MANUAL. Specifications Functional Description Installation Information Operation Maintenance
To accomplish this, the following is provided. INTRODUCTIONThis manual provides information concerning the operation and installation of a SR4A & SR8A Voltage Regulator. INSTRUCTION MANUALFORVOLTAGE REGULATOR Model: SR4A & SR8APart Number: 9 0177 00 XXX
